Features

1.Easy assemble and operation.

2.Safeoperation: workers no need to touch the pile, can just operate the excavator or power pack.

3.Safe and reliable, without any impact on the pile body.

4.Small size: light weight and convenient transportation.

5.Environmental protection: Low-noise, does not affect the surrounding environment during construction.

Technical Parameters

Model	SP400	SP500
Max.cutting diameter (mm)	300-400	400-500
Max.drill rod pressure (KN)	320	320
Max.hydraulic cylinder stroke (mm)	150	150
Max.hydraulic cylinder pressure force (Mpa)	34.3	34.3
Max.working flow of single cylinder (L/min)	25	25
Cutting capacity (pcs/hour)	160/8	120/8
Max. height of single crush (mm)	≤300	≤300
Excavator tonnage (t)	≥8	≥8
Single module weight (kg)	110	200
Single module dimension (LWH)	604×594×286	595×980×275
Operation dimension	1600×1600×2000	1710×1710×2500
Total weight (kg)	650	960
